Crafted with advanced projected capacitive 10-point touch technology, the TM-23 not only delivers smooth and precise touch response, but also enables more creative and exciting interactive applications. Featuring Full HD resolution and an IPS panel, it ensures exceptional and accurate colour performance from all viewing angles. Its height adjustability and tilt flexibility ranging from –5 to 90 degrees guarantee ergonomic-friendliness and multi-user comfort, making it a value choice for public and interactive environments.
Display
Display diagonal: 58.4 cm (23")
Display resolution: 1920 x 1080 pixels
HD type: Full HD
Native aspect ratio: 16:9
Display technology: LCD
Panel type: IPS
Backlight type: LED
Feature: Touchscreen
Touchscreen type: Tabletop
Touchscreen technology: Capacitive
Touch technology: Multi-touch
Number of simultaneous touchpoints: 10
Display brightness (typical): 250 cd/m²
Response time: 5 ms
Screen shape: Flat
Aspect ratio: 16:9
Contrast ratio (typical): 20000000:1
Maximum refresh rate: 60 Hz
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.78 million colours
Pixel pitch: 0.265 x 0.265 mm
Viewable size diagonal: 58.4 cm
Digital horizontal frequency: 30 - 83 kHz
Digital vertical frequency: 55 - 76 Hz
Display diagonal (metric): 58 cm
Surface hardness: 7H
Performance
Operating hours (hours/days): 24/7
Operating system installed: Windows 10
Multimedia
Number of speakers: 2
RMS rated power: 2 W
Feature: Built-in speaker(s)
Design
Market positioning: Business
Product colour: Black
Glass thickness: 2.4 mm
Ports & interfaces
Feature: Built-in USB hub
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports: 4
VGA (D-Sub) ports quantity: 1
Feature: HDMI
HDMI ports quantity: 1
HDMI version: 1.3
DisplayPorts quantity: 1
Audio input: 1
Feature: Headphone out
Headphone outputs: 1
Headphone connectivity: 3.5 mm
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Wall mountable
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Height adjustment
Adjustable height (max): 40 cm
Feature: Tilt adjustment
Tilt angle range: -5 - 90°
Feature: Plug and Play
Power
Power consumption (typical): 14 W
Power consumption (standby): 0.7 W
Power consumption (off): 0.5 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power supply type: Internal
European Product Registry for Energy Labelling (EPREL) code: 619804
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -25 - 55 °C
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 93%
Weight & dimensions
Width (with stand): 561 mm
Depth (with stand): 238.5 mm
Height (with stand): 400 mm
Weight (with stand): 6.6 kg
Width (without stand): 561 mm
Depth (without stand): 57.2 mm
Height (without stand): 338.2 mm
Weight (without stand): 4.3 kg
Packaging data
Package width: 632 mm
Package depth: 448 mm
Package height: 186 mm
Package weight: 8.7 kg
Packaging content
Cables included: AC, Audio (3.5mm), HDMI, USB
Other features
Energy efficiency class (old): B
Compliance certificates: CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Certification: CE, FCC, LVD, BSMI, WEEE, RoHS, REACH, EAC, UKCA
Logistics data
Harmonized System (HS) code: 85285210

AG Neovo TM-23. Display diagonal: 58.4 cm (23"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black
AG Neovo




MBR CODE - TM230011E0100
EAN - 4710739592436
